Project Deep Dive

FML Server Buffer Overflow

A technical assessment of a stack-based buffer overflow vulnerability, resulting in remote code execution via a custom-crafted exploit.

Exploit Development C/C++ Assembly (x86) Memory Forensics x32dbg Metasploit Fuzzing Shellcode

Vulnerability Discovery

Through static analysis of the FML Server source code, I identified a critical flaw in the isASCII() function within parse.c. The server fails to perform bounds checking on user-supplied commands, allowing a 1000-byte buffer to be overrun.

View Exploit Report

Exploit Components

  • Vulnerability: Stack-based Overflow
  • Trigger: HandleConnection() Buffer
  • Payload: Reverse TCP Shell
  • Encoder: shikata_ga_nai
  • Strategy: JMP ESP / NOP Sled

Memory Manipulation

Hijacking the Execution Flow

By utilizing x32dbg and custom fuzzing scripts, I determined the exact offset required to overwrite the EIP (Extended Instruction Pointer). This allowed me to redirect the CPU to a JMP ESP instruction, jumping directly into my malicious payload.

  • Offset Calculation: Pinpointing the crash point in memory.
  • Bad Char Analysis: Identifying characters that break the exploit.
  • NOP Sled: Ensuring reliable execution of the shellcode.
x32dbg Buffer Overflow Debugging

Custom Payload Construction

I used msfvenom to generate a Windows Reverse TCP Shell, specifically avoiding "Bad Characters" found during the assessment. The payload was encoded with shikata_ga_nai to bypass basic detection and ensure the shellcode remained functional within the targeted stack frame.

EIP Overwrite ESP Redirect Return-to-Stack Payload Encoding

Impact Assessment

A successful exploit grants the attacker a full interactive shell on the server host. This allows for total system compromise, including unauthorized file access, lateral movement across the network, and the installation of persistent backdoors.
